DIY Spray Paint Storage Rack

Keep all your spray paint cans in one convenient location with this simple DIY spray paint storage rack! Hang it on the wall with a French cleat for easy access!

DIY spray paint storage rack

My workshop has spray paint cans scattered everywhere, and I never seem to find the color I'm searching for. Then I'll go buy a new can, only to find the one I was looking for as soon as I get home! I decided to make something to keep them all in one spot, where I can see what I have at a glance.

This post contains affiliate links for your convenience. Purchases made through these links may earn me a small commission at no additional cost to you. You can read more about how this site earns money on my disclosures page.

This spray paint storage rack holds up to 25 cans, and is easy to customize to fit your needs. It mounts on the wall with a French cleat, and holds the cans at an angle so they don't roll out or fall over. As an added bonus, it adds a fun pop of color to my workshop wall!

Materials needed for spray paint rack

How to make a spray paint storage rack

Download the plans

You can download the DIY spray paint storage rack plans by clicking the button below! The printable plans include a cut list, step by step instructions with 3D models, and a handy checklist to keep you on track.

spray paint storage rack plans download box

Cut the boards and drill pocket holes

The frame is made with 1x6 boards, and the shelves are 1x4 boards. Cut them all according to the list in the plans.

Drill pocket holes in both ends of all the 1x4 boards, and the shorter 1x6 boards.

pocket holes drilled in both ends of all the shorter boards of the spray paint rack

Cut a spacer block

All the shelves are installed at a 30 degree angle, which can be a little tricky and tedious to measure. I cut a couple spacer blocks to make this process much easier!

spacer block cut at a 30 degree angle at the miter saw

The width of the spacer block matches the height between each shelf. I cut two so I could use one on each side.

Attach the shelves to the sides

Mark the position for the first shelf, then clamp the spacer block in place. The front edge of the spacer lines up with the front edge of the side piece.

spray paint storage rack plans download box

Align the corner of the shelf with the front edge. The pocket holes should be facing up (they'll be covered up with spray paint cans later). Attach the shelf with 1 ¼" pocket hole screws.

attaching first shelf of spray paint storage rack with pocket hole screws

Move the spacer blocks up on top of the first shelf, and clamp them into place. Then attach the next shelf the same way. Keep working your way up until you've assembled all the shelves (without any measuring, yay!)

spray paint storage rack shelves being installed with pocket hole screws

Attach the top, bottom and back

The top and bottom aren't totally necessary, since the shelves are holding the whole rack together. I added a bottom so I could screw some hooks into it for hanging a few painting accessories.

bottom shelf of spray paint storage rack with hooks for painting accessories

But I left off the top because the storage rack will be mounted underneath an existing cabinet in the workshop. (Yes, my workshop walls are weird! This was a garage back in 1946 with dark wood paneling that I painted white so it feels less like a dungeon.)

spot under wall mounted upper cabinet where the spray paint storage rack will be installed

Cut a piece of ¼" plywood to the exact dimensions of the frame, then attach it to the back with brad nails or countersunk screws. You can skip this step (like I did) if you don't mind the cans potentially denting your wall when they slide into place.

Install the French cleat

French cleats are a great way to mount heavy items (like a full spray paint rack) on the wall. You can learn more about how to install a French cleat here.

spray paint storage rack plans download box

Cut a piece of 1x6 board down the middle at a 45 degree angle with a table saw or circular saw. Attach one half to the top of the spray paint rack with the point facing down and away from the back. Countersink the screws so the heads don't interfere with the cleat.

french cleat on back of spray paint rack

I also recommend adding a strip of wood at the bottom to hold the rack straight on the wall. Otherwise, it will tilt under the weight.

strip of wood at bottom of spray paint rack to hold french cleat vertical

Attach the other half of the French cleat to the wall with countersink screws. You'll need to find the studs in the wall or use wall anchors strong enough to hold the weight of all the spray paint cans. One benefit of wood walls is that you can screw into it anywhere! 😉

checking for level on wall side of French cleat

Check that the cleat is level, and has room above it for the other half to slide in (I had to adjust mine down a bit because I didn't leave enough space!)

two halves of french cleat sliding together

Load up your spray paint storage rack

The rack fits this awkward corner between the two cabinets perfectly! There's enough space next to it to add another one as I expand my spray paint collection.

empty spray paint storage rack next to cabinet in workshop

I dug through every cabinet, shelf and bin to round up all my spray paint. Turns out, I had EXACTLY 25 cans! Each shelf holds five cans, so I had just enough room for them all. Looks like I either need to use up a few or build another storage rack!

putting spray paint can on top shelf of spray paint storage rack

I love having all these fun colors at my fingertips, instead of hunting around for the right can! The hooks on the bottom hold several rolls of painter's tape and a spray paint handle, so I'll always be ready for my next project!

spray paint rack filled with different colored cans

Are you ready to get your paint organized? Download the woodworking plans for this spray paint storage rack project and get building!

spray paint storage rack plans download box

Check out these other workshop storage projects!

If you would like to keep up to date with my latest posts about DIY projects, woodworking and more, you can follow me on Facebook, Pinterest, or Instagram. You can also sign up for my email list below and get the latest post delivered to your inbox!

Want more DIY projects?

Subscribe to get project ideas, home improvement tips, woodworking plans and more delivered straight to your inbox!

We won't send you spam. Unsubscribe at any time. Powered by ConvertKit
DIY spray paint storage with step by step plans

how to spray paint like a pro
Spray Paint Tips and Tricks for a Flawless Finish
← Read Last Post
diy wood bead garland
DIY Wood Bead Garland [3 different looks!]
Read Next Post →

17 + 10 =

Ed Eaglehouse

Sunday 18th of April 2021

30 degrees is actually very simple to measure and not very tricky any all. If the height of your piece is at a right angle to its width, or "square", the diagonal of the triangle they make measures 2 times the height. Example: height is 4 inches, diagonal will be 8 inches, angle is 30 degrees. Want 60 degrees? Just flip the width and height.

Sabah

Monday 23rd of November 2020

Thank you for sharing. My husband and I are currently building me a little workshop for all my tools and decorating stuff. I'm definitely building a spray paint holder like yours but much longer. I also like all your other projects which I believe I will be copying. 😊

Veronica

Saturday 14th of November 2020

I couldn't wait to see your paint storage rack. Nice, but it's small. My spray can storage is one of those freestanding sheds that I stacked 12x12 cubes in. I was sure you'd have more cans than I do. Maybe I am a spray paint hoarder like my darling man says.

Vineta

Monday 16th of November 2020

It's easy to make the rack as big as you need, just by lengthening the side pieces. I wanted mine to fit under the cabinet, but there's room for a second one next to it if I run out of room. I don't use spray paint as much as regular paint, but it sounds like you have quite the collection!
